SUPERLITE I 06

HIGHLY EFFECTIVE INSPECTION WITH PUREST UV-LIGHT

FIRST CHOICE FOR NON-DESTRUCTIVE TESTING WITH UV-LIGHT

In close cooperation with leading manufacturers of the aerospace and aviation industry, the SUPERLITE I 06 was developed as a compact and compliant LED light source for the Fluorescent or Liquid Penetrant Inspection. It is the first choice for all applications that need pure UV light free of white light. For orientation or documentation purposes the SUPERLITE I 06 can be switched to white light, using either the front-panel button or the optional foot-switch. The intensity levels of both LED modules can be controlled digitally and independently, settings are saved when switching off the unit. The operation is intuitive and self-explanatory.

POWER VARIANTS FOR DIFFERENT WORKING PLACE REQUIREMENTS

The SUPERLITE I 06 is also available with less powerful UV LED modules to enable an optimal control range especially at short working distances.

HIGH FLEXIBILITY

Thanks to exchangeable adapters the Superlite I 06 can be used with the most common lightguides of various manufacturers. Lumatec Liquid Lightguides are available in various lengths, cross-sections, and with borescope connectors or 90° mirror attachment at the light exit.

Your benefits

  • Compact design
  • Two LED modules for UV and white light, independently controlled
  • Pure UV light free of white light, realized by a dedicated optical system design
  • Compliant with NDT standards for LED lights
  • Seven adapters to match most common industry light guides
  • Compact design, lightweight, and quiet

CONFORMITY

  • ASTM E3022-15
  • MTV 1030-1
  • RRES 90061

BAYONET LIGHT GUIDE ADAPTER FOR:

  • ACMI
  • Lumatec D
  • Machida
  • Olympus
  • Schölly/Volpi
  • Storz
  • Wolf
